Synaptics Astra™ Machina Micro
Introducing the Synaptics Astra Machina Micro
AI MCU Platform for Context-Aware Compute
The Synaptics Astra Machina Micro dev kit enables rapid prototyping for the Synaptics SR100 Series of high performance, context-aware, multimodal AI MCUs. The dev kit brings interfaces and I/O ranging from qSPI for storage, M.2 for connectivity, digital mics for voice processing, and MIPI-CSI for multiple camera inputs. The SR100 series of MCUs - including SR110, SR105, and SR102 deliver AI-accelerated performance at all power levels in combination with ultra low-power multimodal sensing.
Features
Daughter card interface and I/O header options
- MIPI CSI-0, camera sensor input
- MIPI CSI01, output
- General Purpose 20-pin I/O header 1: PDM1, I2S, SDIO0
- General Purpose 20-pin I/O header 2: I2C, SPI UART1, PDM0
- UART0 (4-pin header)
- Debug ports: JTAG, UART
- M.2 E-key 2230 slot for SDIO, UART, PCM
- USB 2.0 Type-C: HS (480Mb/s), device controller
- Push buttons: system reset, PMU enable/ disable, SoC Reset, User button
- Camera and audio mute
- 2-pin header: external Vbat supply optional
- Type-C power supply with 15V @ 1.8A
SR100 Series MCU Dev Kit
- Synaptics SR100 Series SoC
- Storage (xSPI): pSRAM & QSPI
- 2xDMICs • 1 Buck-boost converter
- 1x 3-Axis accelerometer
- 1xALS (Ambient Light Sensing)
Streamline the Development of AI Edge Devices
Enhance Efficiency With On-Device AI
Hit the ground running with AI models already optimized for Synaptics Astra Processors to unlock extensive possibilities. Our solutions also offer seamless integration, letting you take your existing ONNX, PyTorch or TensorFlow Lite models and optimize them for on-device AI accelerators with top-tier embedded AI tools.
Bring Your Edge AI Products to Life
Harnessing the industry's top IoT development system gives you access to compute capabilities, edge AI and integrated wireless connectivity on a single platform. As a modular kit tailored for developers using Astra SL-Series' high-performance IoT processors, Astra Machina lets you easily build and evaluate AI edge devices.
