Product Line Overview

    The new Synaptics Astra SL2610 product line delivers exceptional performance and power efficiency for multimodal compute across IoT devices ranging from smart home appliances, wearables, and smart retail, to robotics, charging infrastructure, and industrial systems. With five pin compatible processor families, it is built for a wide range of AI-native compute solutions from battery-powered and passively cooled devices to high-performance industrial vision systems.

    Experience the groundbreaking Synaptics Torq™ Edge AI platform – with the transformer – and CNN capable Torq T1 NPU together with the industry’s first production implementation of the Coral NPU from Google. This integrated architecture allows for dynamic support of new operators, future-proofing Edge AI IoT system design. Torq advances true AI developer freedom by means of a disruptive, an end-to-end compiler and runtime based on the open-source IREE/MLIR projects, supporting both standard and emerging model formats such as LiteRT, PyTorch, ONNX and JAX.

    Built on a high-efficiency architecture powered by Arm® Cortex®-A55, Cortex-M52, and the Mali™ 3D GPU, the SL2610 processors advance the state of silicon, device, and system-level security, with features ranging from immutable root of trust to application crypto processing – making it well-positioned to address a fast-evolving threat landscape at the IoT AI device edge.



    Blogs

    Trusted by Industry Leaders

    Block Diagram and Features

    sl2610 sl2610 sl2610 sl2610 sl2610 sl2610 sl2610 sl2610 sl2610
    • SL2610 Key Features
    • Peripherals
    • Memory Interface
    • CPU
    • AI Engines
    • System Manager
    • Secure Island
    • Video/GFX
    • Audio
    AI-Native Edge SoC
    Secure Edge Inferencing
    Vision, 3D GFX, Audio
    Pin-to-Pin Compatibility
    Disruptive Price Performance

    Features

    Compute & AI
    • Single and dual core Arm Cortex-A55 SoC domain
    • Arm Cortex-M52 with Helium System Manager domain
    • 1 TOPS Transformer-capable NPU
    • Coral NPU (RISC-V ML Core)
    Graphics, Audio & Multimedia
    • 3D GPU with Arm Mali-G31
    • MIPI-DSI & CSI with 2160p30 and HDR
    • 3x TDM/I2S with 16 channels, support for 8 digital mics
    • Hardware audio and camera mute
    Connectivity & I/O
    • 2 USB-2.0, 2 SDIO 3.0, 4 TWSI I2C, 8 UART
    • 5 SPI, 2 xSPI, 99 GPIO
    • 12-bit ADC and up to 12 smart PWM modules in SM domain
    Security, Memory & Networking
    • DDR4/LPDDR4/DDR3L with inline ECC
    • PSA certified Level 3 (RoT), Level 2 (Product)
    • Secure boot, TRNG, RSA, AWS, SHA, ECC, HASH
    • Single and Dual GbE RGMII with Wake-on-LAN
    • 1588 PTP and TSN, 802.1 p/q VLAN tagging

    Benefits

    • IoT-specific feature integrations minimize overall system cost
    • Industry-leading performance/watt/$ with secure, AI-native compute
    • Build future-ready IoT designs supporting multimodal GenAI workloads
    • Reduce time to market with open-source, developer-friendly Edge AI software

    Applications

    • Home appliances and automation
    • Home consumer goods
    • Industrial process and control systems
    • Smart retail and charging infrastructure
    • Healthcare diagnostics systems
    • Casual gaming
    • Robotics and UAVs

    Astra Machina SL2610 Dev Kit


    The Synaptics Astra Machina SL2600 Series development kit enables easy and rapid prototyping of multimodal AI-native IoT applications. A flexible design approach supports a core compute module, an I/O base board, daughter cards for integrated Wi-Fi / Bluetooth connectivity, debug, and programmable I/O. The evaluation system supports the Synaptics SL2619 SoC family that delivers unprecedented levels of price performance for the IoT, and enabled via an open, unified software experience built on Yocto Linux. The Machina SL2600 Series is powered by the open-source Synaptics Torq™ Edge AI platform, leveraging the Coral Open NPU subsystem.


    Download Product Brief Register Your Interest
    Astra Machina Micro

    Documentation


    Type Title Revision Date
    Product Brief ASTRA MACHINA SL2600 SERIES DEVELOPERS KIT PRODUCT BRIEF
    Product Brief ASTRA SL2600 SERIES GENAI IOT PROCESSORS - SL2610 PRODUCT LINE BRIEF
    Datasheet SL2610 PRODUCT LINE OF EMBEDDED PROCESSORS DATASHEET
    User Guide or TRM ASTRA MACHINA SL2600 SERIES DEVELOPER KIT USER GUIDE
    Application Note ASTRA MACHINA FOUNDATION SERIES CONNECTION OF A KEYPAD APPLICATION NOTE
    Application Note ASTRA MACHINA FOUNDATION SERIES EMMC APPLICATION NOTE
    Application Note ASTRA MACHINA FOUNDATION SERIES GENERAL MIPI DSI LCM HARDWARE CONNECTION APPLICATION NOTE
    Application Note ASTRA MACHINA FOUNDATION SERIES I2S, PDM INTERFACES APPLICATION NOTES
    Application Note ASTRA MACHINA FOUNDATION SERIES MIPI-CSI CAMERA HARDWARE CONNECTION APP NOTE
    Application Note ASTRA MACHINA FOUNDATION SERIES POE HARDWARE CONNECTION
    Application Note ASTRA MACHINA FOUNDATION SERIES TWSI APPLICATION NOTE
    Application Note ASTRA MACHINA FOUNDATION SERIES UART APPLICATION NOTE
    Application Note ASTRA MACHINA SL2600 SERIES BOUNDARY SCAN & JTAG INTERFACE APPLICATION NOTES
    Application Note ASTRA MACHINA SL2600 SERIES HARDWARE PLATFORM GPIO PIN MULTIPLEXING
    Application Note ASTRA MACHINA SL2600 SERIES INTERFACE TO 10BASE-T1S ETHERNET APPLICATION NOTE
    Application Note ASTRA MACHINA SL2600 SERIES SD AND SDIO HOST APPLICATION NOTE
    Application Note ASTRA MACHINA SL2600 SERIES XSPI APPLICATION NOTE
    Application Note ASTRA MACHINA SL2600-SERIES POWER CONSUMPTION
    Application Note ASTRA MACHINA SL2610 - PMIC SOLUTION FOR RDK
    Application Note ASTRA™ MACHINA FOUNDATION SERIES SPI APPLICATION NOTE
    Application Note GENERAL ESD/EOS CONTROL METHODS APPLICATION NOTE
    Application Note GENERAL GUIDE FOR SOLDERING SMD TO PC BOARDS APPLICATION NOTE
    Application Note SL2610 GENERAL PCB DESIGN AND DDR4 & LPDDR4(X) & DDR3L INTERFACE LAYOUT GUIDELINES
    Board Related RELEASE PACKAGE, SL16X0 RDK IO SCHEMATIC BOARD
    Board Related RELEASE PACKAGE, SL2610 CORE MODULE, SCHEMATIC DDR4 RDK BOARD
    General SL2610 PRODUCT LINE QUALIFIED COMPONENT LIST

    Define Your AI Journey

    On-Device AI in Minutes

    Get started today with AI models pre-optimized for Synaptics Astra Processors, and discover the possibilities. Optimize PyTorch, ONNX or TensorFlow Lite models for on-device AI accelerators with best-in-class embedded AI tools.

    Designed With Usability in Mind

    Astra Machina is the industry’s premier IoT system for compute, edge AI technology and connectivity built on open software. Modular developer kit for Astra SL-Series of high-performance IoT processors with integrated Wireless Connectivity from Synaptics.
